Motoman GP8
Motoman GP8 Multi-Purpose 6-Axis Handling Robots Motoman GP8 The MOTOMAN GP8, one of our most successful robot models ever, is an extremely agile, compact and universal robot with
Xem chi tiết →Motoman GP12 FGG
6-axis Robot for the Food Industry
Motoman GP12 FGG
- The GP12 FGG is a highly versatile 6-axis robot with 12 kg payload, 1440 mm reach and outstanding repeatability of +/- 0.02 mm.
- Specifications like high IP65/67 (dust/liquid proof) protection rating, food grade grease lubrication in all joints, and a a special drip proof coating allows the robot to be used in certain food related applications.
- You will achieve high transfer rates with this extremely fast and efficient GP12 FGG robot, which offers a perfectly tuned payload / speed / wrist allowable moment in it’s class.
- Designed with the latest YASKAWA Sigma7-Servo Motor Generation, the GP12 FGG offers improved acceleration/deceleration control.
- The small footprint and slim arm design allows for minimum installation space and minimizes interference with peripheral devices. Installation is quick and efficient – media cables are guided through the hollow arm and wrist structure.
Motoman GP12 FGG Specification
- NUMBER OF AXES 6
- PAYLOAD 12 kg
- MAX. WORKING RANGE 1,440 mm
- REPEATABILITY 0.02 mm
- WEIGHT 155 kg
- POWER SUPPLY 1.5 kVA
- S AXIS 260 °/s
- L AXIS 230 °/s
- U AXIS 260 °/s
- R AXIS 470 °/s
- B AXIS 470 °/s
- T AXIS 700 °/s
- MOUNTING OPTIONS Ceiling, Wall, Floor
